Canon Create a 120 Megapixel CMOS Sensor

Canon has created a new 120 megapixel CMOS sensor that is capable of capturing images at a resolution of 13,280 x 9,184 pixels. According to the Canon press release, this makes it about 7.5 times larger with a 2.4 fold improvement in resolution when compared to the highest-resolution commercially available CMOS sensor that measures the same size.

The 120 megapixel sensor is an APS-H sized device that measures 29.2 x 20.2 mm in size.

It isn’t clear at the moment what Canon will be using this sensor for. We suspect that it wont be coming to a regular DSLR any time soon though.

Press Release below…

TOKYO, August 24, 2010‚ÄĚCanon Inc. announced today that it has successfully developed an APS-H-size*1 CMOS image sensor that delivers an image resolution of approximately 120 megapixels (13,280 x 9,184 pixels), the world’s highest level*2 of resolution for its size.

Compared with Canon’s highest-resolution commercial CMOS sensor of the same size, comprising approximately 16.1 million pixels, the newly developed sensor features a pixel count that, at approximately 120 million pixels, is nearly 7.5 times larger and offers a 2.4-fold improvement in resolution.*3

With CMOS sensors, while high-speed readout for high pixel counts is achieved through parallel processing, an increase in parallel-processing signal counts can result in such problems as signal delays and minor deviations in timing. By modifying the method employed to control the readout circuit timing, Canon successfully achieved the high-speed readout of sensor signals. As a result, the new CMOS sensor makes possible a maximum output speed of approximately 9.5 frames per second, supporting the continuous shooting of ultra-high-resolution images.

Canon’s newly developed CMOS sensor also incorporates a Full HD (1,920 x 1,080 pixels) video output capability. The sensor can output Full HD video from any approximately one-sixtieth-sized section of its total surface area.

Images captured with Canon’s newly developed approximately 120-megapixel CMOS image sensor, even when cropped or digitally magnified, maintain higher levels of definition and clarity than ever before. Additionally, the sensor enables image confirmation across a wide image area, with Full HD video viewing of a select portion of the overall frame.

Through the further development of CMOS image sensors, Canon will break new ground in the world of image expression, targeting new still images that largely surpass those made possible with film, and video movies that capitalize on the unique merits of SLR cameras, namely their high mobility and the expressive power offered through interchangeable lenses.

*1 The imaging area of the newly developed sensor measures approx. 29.2 x 20.2 mm.
*2 As of August 20, 2010. Based on a Canon study.
*3 Canon’s highest-resolution commercial CMOS sensor, employed in the company’s EOS-1Ds Mark III and EOS 5D Mark II digital SLR cameras, is equivalent to the full-frame size of the 35 mm film format and incorporates approximately 21.1 million pixels. In 2007, the company successfully developed an APS-H-size sensor with approximately 50 million pixels.

Via: Photography Blog
